CommScope CAT5e 3m Grey Patch Cord
Brand: CommScope
- Delivered nationwideDoor-to-door, anywhere in South Africa
- 1Year WarrantyLocal support
- 7-day returnsChange your mind within 7 days of delivery. Returns policy
- Secure checkoutPaid on an encrypted payment page
Description
The CommScope NETCONNECT CO155E2-0CM003 is a 3 m Category 5e U/UTP patch cord in grey, with an RJ45 plug on each end wired to T568B. It suits linking network equipment such as switches, patch panels and wall outlets.
The four-pair cable has stranded 24 AWG tinned copper conductors in a Low Smoke Zero Halogen (LSZH) jacket, and the plug contacts are gold over nickel. CommScope lists ANSI/TIA-568.2-D and ISO/IEC 11801 Class D as its transmission standards.
Key points
- Category 5e U/UTP, 3 m, grey
- LSZH jacket, 5.97 mm diameter
- Supports IEEE 802.3bt Type 4 (90 W) PoE applications
- UL 94 V-0 flammability rating
- Operating temperature -10 °C to +60 °C
Product information
- Brand
- CommScope
- SKU
- CO155E2-0CM003
- Warranty
- 1Year Warranty
- Category
- ANSI/TIA Category 5e
- Cable type
- U/UTP (unshielded)
- Length
- 3 m
- Colour
- Grey
- Connectors
- RJ45 plug (standard) both ends
- Wiring
- T568B
- Pairs
- 4
- Conductor
- 24 AWG stranded tinned copper
- Jacket material
- Low Smoke Zero Halogen (LSZH)
- Diameter over jacket
- 5.97 mm (0.235 in)
- Transmission standards
- ANSI/TIA-568.2-D, ISO/IEC 11801 Class D
- PoE support
- IEEE 802.3bt Type 4 (90 W)
- Contact plating
- Gold over nickel
- Operating temperature
- -10 °C to +60 °C
- Flammability rating
- UL 94 V-0
